Description
Charge and use your lithium battery with the TP4056 Battery Charging Module with Output Protection! Simply connect the ends of the battery to the BAT+ and BAT- terminal of the module, the load to the OUT+ and OUT- of the terminal and power the module with a 5V power supply from the USB C port.
Output Protection ensures that your lithium ion battery's voltage does not fall below 2.5V and ensures that the current draw from the battery does not exceed 3A by cutting off the output when either conditions are met.
Input Voltage: 5V
Charging Current: 1A
Charging Voltage: 4.2V
Charging Voltage Accuracy: 1%
Output Voltage Threshold: 2.5V
Output Current Threshold: 3A
Connector Type: USB C
Charging Indicator: Red LED Steady ON
Full Charge Indicator: Blue LED Steady ON
Dimensions: 26 x 17 x 3mm
Weight: 2g
Output Protection ensures that your lithium ion battery's voltage does not fall below 2.5V and ensures that the current draw from the battery does not exceed 3A by cutting off the output when either conditions are met.
Input Voltage: 5V
Charging Current: 1A
Charging Voltage: 4.2V
Charging Voltage Accuracy: 1%
Output Voltage Threshold: 2.5V
Output Current Threshold: 3A
Connector Type: USB C
Charging Indicator: Red LED Steady ON
Full Charge Indicator: Blue LED Steady ON
Dimensions: 26 x 17 x 3mm
Weight: 2g
Customer Reviews
Based on 7 reviews
100%
(7)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
o
.
Thank you very much for your purchase and review! Have a great day! :)\n
1
Receive items on time. Yet to test it out
Thank you very much for your review! Have a great day!
n
Fast delivery good service
Thank you very much for your purchase! All the best for your projects and have a great day! :)
t
I think it doesn't have 5.1k pulldown on the CC lines which PD devices need before giving power. Means that this works with USB-A to C cables and not USB-C to C cables.
There's pads for input voltage which I could solder on a separate USB-C connector to overcome this. Other than that, works great!
j
Quite good quality
